WT3001-12-N

THE WT3000 IS A GENERAL PURPOSE MEDIUM CAPACITY THERMOSTATIC TRAP THAT CAN BE USED FOR STEAM TRACING; AS A DRIP TRAP ON STEAM MAINS AND STEAM SUPPLY LINES; AS WELL AS FOR PROCESS APPLICATIONS. ALL INTERNAL WORKING COMPONENTS CAN BE REPLACED WHILE THE TRAP BODY REMAINS IN-LINE. THERMOSTATIC TRAPS ARE SMALL, LIGHT WEIGHT, OPERATE OVER A WIDE PRESSURE RANGE, AND HAVE EXCELLENT AIR HANDLING CAPABILITIES. DISCHARGING AIR AT START-UP ALLOWS STEAM TO QUICKLY ENTER THE SYSTEM. ALL STAINLESS STEEL CONSTRUCTION AND INTEGRAL STRAINER OPTION MAKE THE WT3000 AN EXCELLENT CHOICE FOR A VARIETY OF APPLICATIONS. CONTAINS AN EXTREMELY STRONG AND RUGGED PRECISION WELDED STAINLESS STEEL THERMAL ELEMENT WHICH IS HIGHLY RESISTANT TO WATERHAMMER.
