B-14-N-2-V
THE B-SERIES DIRECT-OPERATED PRESSURE REGULATORS WITH BALANCED VALVE TRIM ARE USED FOR REDUCING PRESSURE IN AIR AND WATER SYSTEMS. THESE REGULATORS ARE COMMONLY FOUND IN INDUSTRIAL PLANTS, APARTMENT BUILDINGS, WATER SUPPLY SYSTEMS, SCHOOLS AND UNDERGROUND WATER DISTRIBUTION SYSTEMS. THE SOFT-SEATED ELASTOMERIC VITON DISC HAS AN OPERATING TEMPERATURE UP TO 300°F AND WILL PRODUCE A CLASS V SHUTOFF. NO EXTERNAL SENSING LINE IS REQUIRED WITH THIS STYLE OF REGULATOR.
| Technical Specification |
| Service | Liquids, Gases |
| Size | 1" |
| Connection | NPT |
| Reduced Pressure Range (psig) | 20 - 70 |
| Max. Inlet Pressure (psig) | 250 |
| Min. Inlet Pressure (psig) | 10 |
| Max. Differential Pressure (psig) | 125 |
| Min. Differential Pressure (psig) | 20% of Inlet Pressure |
| Material Specification |
| Body | Bronze |
| Seat | Stainless Steel |
| Disc | Viton-300F max |
| Diaphragm | Viton-300F max |
