S-PMPC-2X2-SS-21

THE PMPC SERIES (CAST DUCTILE IRON PUMP BODY MATERIAL) WITH A VENTED RECEIVER. STANDARDIZED SIMPLEX, DUPLEX, TRIPLEX, AND QUADRAPLEX PACKAGED SYSTEMS INCLUDE STAND-ALONE PUMP(S), CHECK VALVES AND VENTED RECEIVER, MOUNTED ON A STEEL BASE AND FRAME. MULTIPLE PUMPING UNITS CAN BE USED FOR INCREASED CAPACITY OR FOR SYSTEM REDUNDANCY. THE PMP UNITS ARE AVAILABLE IN DUCTILE IRON, CARBON STEEL AND STAINLESS STEEL. ADDITIONAL OPTIONS INCLUDE SIGHT GLASSES, INSULATION JACKETS, CYCLE COUNTERS, MOTIVE AND VENT PIPING, PRESSURE REGULATORS, STEAM TRAPS, STRAINERS, ASME CODE STAMPS, ETC. INCLUDES: HEAVY-DUTY PUMP, STEEL RECEIVER, ISOLATION VALVE(S), SS CHECK VALVES, SCHEDULE 40 PIPING, ANDÂ MOUNTED ON A STEEL BASE.
