SUCT-13-N-CI-125
THE WATSON MCDANIEL CAST IRON, BRONZE OR STAINLESS STEEL SUCTION TEE IS A SPECIALIZED TYPE OF PIPE FITTING USED FOR BLENDING, AGITATION, RECIRCULATION, MIXING, AERATION AND HEATING.
| Technical Specification |
| Size | 3/4" |
| Connection | NPT |
| Max. Operating Pressure (psig) | 125 |
| Weight (lbs) | 2.50 |
| Dimension | 5(A),1.88(B),3.13(C),3.13(D),0.38(E) |
| Material Specification |
| Body | Cast Iron, A126 CLASS 30 |
| Plug | Cast Iron, A126 CLASS 30 |
