WFT-175-13-N
WFT SERIES WITH PARALLEL PORT CONNECTIONS WERE SPECIFICALLY DESIGNED FOR REMOVING CONDENSATE AND AIR FROM HVAC AND INDUSTRIAL PROCESS APPLICATIONS SUCH AS UNIT HEATERS, PRESSING MACHINES, HEAT EXCHANGERS AND COILS. THEY CONTAIN A HIGH-QUALITY WELDED STAINLESS STEEL THERMOSTATIC AIR VENT AND STAINLESS STEEL MECHANISM. THE WFT SERIES ARE FULLY REPAIRABLE WHILE THE TRAP REMAINS IN-LINE AND ARE AVAILABLE IN 3/4" THRU 2" NPT CONNECTIONS. FOR DRIP APPLICATIONS, SUCH AS DRAINING STEAM MAINS AND STEAM SUPPLY LINES, USE MODEL 3/4 WFT-125 (WFT-125-13-N).
| Technical Specification |
| Size | 3/4" |
| Connection | NPT |
| Weight (lbs) | 24 |
| Max. Operating Pressure (psig) | 175 |
| Max. Allowable Pressure (psig) | 250 PSIG up to 450°F |
| Material Specification |
| Body | Cast Iron |
| Cover | Cast Iron |
| Seat | Stainless Steel,17-4 PH |
| Disc | 420F SS |
| Thermostat | 304 SS |
| Float | Stainless Steel |
| Internals | Stainless Steel |
| Cross Reference |
| Spirax Sarco | FT-150 |
